The working principle of oil gas pipeline flame arrester is mainly based on heat transfer and wall effect. When the burning flammable gas passes through the narrow passage of the flame arrester, the flame is divided into multiple small flames, which reduces the temperature of each flame so that it cannot reach the ignition point. At the same time, the design of the fire blocking element increases the contact area between the flame and the channel wall, strengthens the heat transfer effect, and further reduces the flame temperature. In addition,Tank Explosion proof flame arresters the collision probability between the free radicals in the flame and the channel wall increases, reducing the number of free radicals involved in the reaction, thereby preventing the continued propagation of the flame.
stainless steel Oil gas pipeline flame arrester Product characteristics：
Compact construction: Oil gas pipeline flame arresters are usually designed in a compact way to save installation space.
High reliability: Through the introduction of foreign advanced technology and combined with domestic independent research and development of stainless steel explosion-proof corrugated fire retardant plate, improve the reliability and stability of the flame arrester.
Material: Cast steel, stainless steel 304, 304L, 316, 316L
Connection method: flange, internal thread, welding
Explosion-proof, anti-corrosion, fire resistance performance: the flame arrester core is made of stainless steel corrugated plate and other materials, with explosion-proof, anti-corrosion, fire resistance performance.
Easy to clean: The flame arrester core is easy to clean and maintain, which can maintain its long-term stable performance.
